Inner Part of CH405 KAS Ceramic Insulated Cooling Heater
CH-405-KAS-I

It is inner part CH405KAS air cooling heater

It is produced according customer's demand.

Technical Specification
Watt:  Max. 6,5W/cm²
Max. Working Temperature: 400 °C
Width of seperator: 30mm, 45mm, 60mm, 75mm
Housing material:  Stainless steel
Insulation material: Max 1200  °C Steatit
Resistance winding wire:  80/20 NiCr 1200°C
Energy Connection: Ni GLS cable resistant to 400°C and  connection box
